This electric seed spreader mainly consists of a fertilizer box, a fertilizer box frame, a tractor coupling device, a fertilizer amount adjustment device, a throwing tooth plate, a throwing tooth plate driving DC motor, a DC motor speed regulator, etc. The DC motor is powered by the tractor battery, and the throwing tooth plate is driven by the motor to rotate. The fertilizer discharged from the bottom of the fertilizer box falls into the throwing tooth plate. Under the high-speed rotation of the tooth plate, the fertilizer is thrown out from the tangent of the tooth plate, completing the process of spreading fertilizer. The width of the throwing fertilizer can be adjusted.
As a professional factory of electric seed spreader, please kindly check the below the specification :
| Model | TF-300 |
| Volume(KG) | 100 |
| Disc | 1 |
| Hopper Material | Polyethylene Hopper |
| Working Width(M) | 3-10 |
| Dimension(MM) | 780*580*820 |
| Weight(KG) | 21 |
| Matched Power(V) | 12 |
| Matched Rate(Ha/H) | 1.6-2 |
(1) Front bumper hitch: Screw and nut linkage tractor suspension;
(2) 12V electric linkage: Tractor battery as power support;
(3)Strong ABS spreading disc;
(4)Strong iron frame with painting;
(5)Shielded front plate to prevent spreading of material in front of spreader;
(6)Adjustable positions to obtain maximum spreading precision;
(1)The electric seed spreader is simple to use and can make your field spraying work fast and even. It is more than 50 times that of manual work, reducing the labor intensity of manual scattering. In addition to saving work time, a uniform scattering effect can also bring greater production and economic benefits.
(2)The adjustment handle of the electric seed spreader can freely adjust the amount of seeds and fertilizers scattered; the machine is equipped with an adjustment switch that allows you to freely adjust the throwing width.
(3)The electric seed spreader has a wide range of applications, including various granular fertilizers, wheat, beans, herb seeds, and snow melting agents for road sowing.
Our electric seed spreaders adopt advanced technology and high-quality materials, featuring high efficiency, precision, stability and many other advantages. They can meet the needs of farmland of different scales and demands. We look forward to your purchase!
