| 504 Technical Specifications | ||
| Name | Unit | Technical specifications |
| Model and name | / | 504-X Type wheel tractor |
| Machine Type | / | Wheel type |
| Drive Type | / | Four-wheel drive |
| Size of machine (length x width x height ) | mm | 3300x1620x2350 |
| Wheelbase or track grounding length | mm | 1850 |
| Common wheel pitch (front / rear wheel) or distance | mm | 1300/1300 |
| Wheelbase(front / rear wheel) or gauge | mm | 1200、1300/1200, 1300 |
| Minimum ground clearance and part | mm | 330 Front bridge bottom |
| Minimum use quality | kg/kW | 1700 |
| Minimum use ratio to mass | kg/kW | 46.19 |
| Number of gears (forward/reverse) | / | 8/2 |
| Number of Main Gears | / | 4+1 |
| Number of Subshift Gears | / | 2 |
| Engine to Main Clutch Connection | / | Direct connection |
High-crop tractors can pass through the fields, greatly reducing damage to plants and increasing crop yields.
The high-crop tractor can travel between crop fields with different row spacing, reducing time. At the same time, it can be equipped with a variety of agricultural implements to complete a variety of operations, improving the overall efficiency of farmland operations.
High-crop tractors can operate on farmland terrains and can also operate under complex terrain .
Comfortable seats and convenient operating controls reduce operator time and improve work comfort and safety.
If you have any questions about high crop tractor, welcome to contact
us!
